Trụ sạc nhanh DC cho ô tô điện 30KW, 40KW, 60KW
* Xuất xứ : Trung Quốc
* Điện áp vào : 380 VAC ± 15%
* Điện áp ra : 200-750VDC
* Dòng sạc : 5A~200A
* Công suất tối đa :30KW 40KW 60KW
* Kích thước : 1254*690*243
* Lớp bảo vệ : IP54
Mô tả
Thông số sản phẩm
| MODEL |
30KW |
40KW |
60KW |
| INPUT | |||
| Nominal Input Voltage | 380 VAC ± 15% | ||
| Acceptable Input Voltage Range | 3-phase, 3ph + N + PE | ||
| Working Voltage Range | 50 – 60 Hz | ||
| Maximum Input Current |
5-200A |
5-200A |
5-200A |
| Frequency Range |
≦ 5% |
||
| Input Power Factor | > 0.99 @nominal voltage (100% load) | ||
| OUTPUT | |||
| Output Current Range (based on 2-output) |
5-200A |
5-200A |
5-200A |
| Output Voltage Range |
200~750VDC (600~750VDC in constant power mode) |
||
| Power Module |
15kW x 2 pcs |
20kW x 2 pcs |
30kW x2 pcs |
| Efficiency | > 94% | ||
| Module Output Current Unbalancce | < 5% | ||
| Module Output Voltage Ripple |
< 0.5 |
||
| Module Output Voltage Precision | < 0.5% | ||
| MModule Output Current Precision | < 1% | ||
| Connector Single Mode (max.) | yes | yes | yes |
| Connector Double Mode (max.) | no | yes | yes |
| Power Distribution | Single plug mode / Average output mode | ||
| PROTECTION | |||
| Charger Safety Protection | Over/Under voltage, overload, output power limit function, short circuit, anti-access, earth leakage, lightning and overheat protection | ||
| Interface Safety Portection | Circuit discharge function, insulation monitoring device (IMD) and battery reverse parity protection | ||
| USER INTERFACE | |||
| Status Indiators | Power on, charging and fault | ||
| Communication Protocol | OCPP 1.6 | ||
| Connection Communication Mode | In accordance with DIN 70121 and ISO 15118 standard | ||
| Connection Standard |
CCS2 (IEC61851-23) and CHAdeMO 1.0 |
||
| ENVIRONMENT | |||
| Operating Temperature | -25°C to 50°C | ||
| Humidity | 0 – 95% (non-condensing) | ||
| Altitude | < 2000m | ||
| Noise Level | <65dB | ||
| PHYSICAL | |||
| IP Protection | IP54 | ||
| Cable Length | 5m | ||
| Dimension, D x W x H (mm) |
1254mm*690mm*243 excluding plug and cable |
||
| Net Weight (kgs) |
230 |
240 |
260 |
